| 23 | 25 | 28 | 30 | 33 | |
|---|---|---|---|---|---|
| Zoom a plat [%] | 91.2 | 95.5 | 100 | 104.3 | 109.3 |
| Surface a plat [m2] | 23.22 | 25.57 | 28.04 | 30.5 | 33.5 |
| Surface projetee [m2] | 20.88 | 22.9 | 25.12 | 27.33 | 30.01 |
| Envergure a plat [m] | 11.04 | 11.55 | 12.1 | 12.62 | 13.22 |
| Allongement a plat | 5.22 | 5.22 | 5.22 | 5.22 | 5.22 |
| Corde moyenne[m] | 2.62 | 2.74 | 2.87 | 3 | 3.14 |
| Nb de cellules | 52 | 52 | 52 | 52 | 52 |
| Poids [kg] | 5.8 | 6 | 6.2 | 6.5 | 6.8 |
| Fourchette de poids PTV *[kg] | 62 - 82 | 77 - 97 | 85 - 110 | 100 - 130 | 115 - 145 |
| Vitesse mini[km/h] | 23 - 25 | 23 - 25 | 23 - 25 | 23 - 25 | 23 - 25 |
| Vitesse max [km/h] | 36 - 38 | 36 - 38 | 36 - 38 | 36 - 38 | 36 - 38 |
| Vitesse max (acceleree)[km/h] | 48 - 50 | 48 - 50 | 48 - 50 | 48 - 50 | 48 - 50 |
| Finesse max | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 |
| Taux de chute mini [m/s] | 1.15 | 1.15 | 1.15 | 1.15 | 1.15 |
| Homologation | EN B | EN B | EN B | EN B | EN B |
|
* PTV = poids nu + environ 20 kg |
|||||
