Muse 3 | MAC PARA

Muse 3	21	24	26	28	31	34
Zoom flat [%]	87	92	95.7	100	104.5	111
Area flat [m²]	21.24	23.75	25.7	28.06	30.64	34.57
Area projected [m²]	19.48	21.78	23.56	25.73	28.1	31.7
Span flat [m]	10.31	10.9	11.34	11.85	12.38	13.15
Aspect ratio flat	5	5	5	5	5	5
Root cord [m]	2.54	2.69	2.79	2.92	3.05	3.24
Cells	45	45	45	45	45	45
Weight [kg]	4.7	4.95	5.1	5.3	5.6	5.9
Weight range *[kg]	58 - 75	67 - 85	75 - 95	85 - 110	105 - 135	115 - 150
Weight range *[lbs]	128 - 165	148 - 187	165 - 209	187 - 243	231 - 298	254 - 331
Min. speed [km/h]	23 - 25	23 - 25	23 - 25	23 - 25	23 - 25	23 - 25
Trim speed [km/h]	36 - 38	36 - 38	36 - 38	36 - 38	36 - 38	36 - 38
Top speed (accelerator)[km/h]	44 - 46	45 - 47	45 - 47	45 - 47	45 - 47	45 - 47
Glide ratio	8.2	8.3	8.3	8.3	8.3	8.3
Min. sink rate [m/s]	1.05	1.05	1.05	1.05	1.05	1.05
* pilot equipped = weight naked + cca. 20 kg (44 lbs)

Muse³
